Swimming Pool Heat Pump Water Heater
Detailed Product Description: Our swimming pool heat pump 3.8KW-14KW can be installed in many environments, including a constant temperature swimming pool, sauna constant hot water system, or to supply hot water at home.
Striking characters distinguishing from other products.
1.Automatic operation mode，Auto-restart, Automatic defrost.
2.LCD Control panel with luxury outlook.
3.Cooling&heating function.
4.Wide ambient range : -10°C to 43°C
Other main characters.
1) Long operating life: Using the advanced stainless steel/titanium metal water heat exchanger, which resists the erosion from chlorine in the water, creates a longer lifespan.
2) Economical and high-efficiency: Using heat pump technology, compared with other ordinary hot water equipment (for example, combustion oil boilers, combustion gas boilers, electronic boilers and so on), it reduces operating costs by 65-80%, In addition it creates very little pollution.
3) Bright design, easy installation and replacement: Unit design separately for main model and water unit model, with water unit inside, avoiding freezing in the winter. The unit is remarkably compact, with pump and flow switch inside.
4) Advanced controlling: It is extremely easy to control through the mini-computer intelligent controlling .
5) Safety: Water and electricity are well insulated, no risk of fiire and short circuit.
6) Quiet: Using the high-efficiency, low sound rotary or scroll Japanese brand compressor, low noise fan, high quality pump, creates an extremely quiet machine.
7) High technology heat exchangers: Due to Top quality Titanium heat exchanger, it runs more efficiently.
Swimming Pool Heat Pump 3.8KW, 5.3KW, 7.8KW, 9.5KW,12.5KW,14KW
Specification data
| Model | 07 | 10 | 12 | 15 | 21 | ||
| Ambiancy 28°C/Humidity 80%,Water 28°C | |||||||
| Boost Mode | Heating capacity | W | 7,500 | 10,200 | 11,860 | 15,120 | 20,370 |
| COP | – | 6.5-5.5 | 6.4-5.4 | 6.8-5.7 | 6.4-5.3 | 6.4-5.4 | |
| Smart Mode | Heating capacity | W | 7,500-2900 | 10,200-3,400 | 11,860-3,950 | 15,120-5,300 | 20,370-6,800 |
| COP | – | 11.0-5.5 | 10.8-5.4 | 11.1-5.7 | 10.8-5.3 | 11.4-5.4 | |
| Eco Mode | Heating capacity | W | 4,800-2,900 | 6,400-3,400 | 7,350-3,950 | 9,500-5,300 | 12,600-6,800 |
| COP | – | 11.0-8.5 | 10.8-8.4 | 11.1-8.6 | 10.8-8.4 | 11.4-8.7 | |
| Ambiancy 15°C/Humidity 70%,Water 26°C | |||||||
| Boost Mode | Heating capacity | W | 6,200 | 8,600 | 10,600 | 12,500 | 14,800 |
| COP | – | 5.0-4.5 | 4.9-4.4 | 5.2-4.6 | 5.0-4.5 | 5.1-4.6 | |
| Smart Mode | Heating capacity | W | 6,200-2,200 | 8,600-3,000 | 10,600-3,800 | 12,500-4,200 | 14,800-5,000 |
| COP | – | 6.8-4.5 | 6.7-4.4 | 6.9-4.6 | 6.8-4.5 | 6.9-4.6 | |
| Eco Mode | Heating capacity | W | 5,900-4,100 | 8,200-5,400 | 10,100-6,600 | 11,900-7,700 | 14,100-9,100 |
| COP | – | 6.8-5.5 | 6.7-5.4 | 6.9-5.6 | 6.8-5.5 | 6.9-5.6 | |
| Gas | Type | – | R32 | ||||
| Quantity | g | 600 | 700 | 1,000 | 1,200 | 1,400 | |
| Noise level | 1 m | dB(A) | 39-50 | 40-51 | 41-52 | 42-53 | 45-56 |
| 10 m | dB(A) | 20-30 | 21-31 | 22-34 | 22-35 | 25-36 | |
| Water | flow | m3/h | 2-4 | 2-4 | 4-6 | 4-6 | 6-8 |
| Max pressure | bar | 3 | 3 | 3 | 3 | 3 | |
| connections | – | G1.5″ / PVC 50 mm | |||||
| Power supply | – | 230V / 1~ / 50 Hz | |||||
| Nominal intensity | A | 4.5 | 5.5 | 7.0 | 9.0 | 11 A | |
| Maximum intensity | A | 7.0 | 8.2 | 10.5 | 11.5 | 15 A | |
| Dimentions (L x W x H) | mm | 936 x 322x 567 | 936 x 322x 567 | 1006x 342 x 625 | 1006x 342 x 625 | 1025 x 413 x 752 | |
| Net weight | kg | 42 | 46 | 53 | 59 | 68 | |
| Packing | mm | 1045 x 400 x 700 | 1045 x 400 x 700 | 1120x 420x 755 | 1120x 420x 755 | 1140 x 490 x 880 | |
| Gross weight | kg | 53 | 57 | 64 | 70 | 83 | |
| POOL SIZE REF | m3 | 30-45 | 45-55 | 55-70 | 85-105 | 105-130 | |
