1.Automatic operation mode
2.Auto-restart, Auto defrost.
3.LCD Control panel with luxury outlook.
4.Cooling&heating.
5.Wide ambient range : -10 centigrade to 43centigrade
6.Japanese brand compressor
7.Green refrigerant R410
Les autres personnages principaux.
1) Long operating life: Using the advanced stainless steel/titanium
metal water heat exchanger, which resists the erosion from chlorine
in the water, creates a longer lifespan.
2) Economical and high-efficiency: Using heat pump technology, compared
with other ordinary hot water equipment (for example, combustion oil
boilers, combustion gas boilers, electronic boilers and so on), it
reduces operating costs by 65-80%, In addition it creates very little
pollution.
3) Bright design, easy installation and replacement: Unit design
separately for main model and water unit model, with water unit
inside, avoiding freezing in the winter. The unit is remarkably
compact, with pump and flow switch inside.
4) Advanced controlling: It is extremely easy to control. The swimming
pool heat pump unit is in the room, because of the mini-computer
intelligent controlling .
5) Safety: Water and electricity are insulated, no open fire, no creepage.
6) Quiet: Using the high-efficiency, low sound rotary or scroll compressor,
low noise fan, high quality pump, creates an extremely quiet machine.
7) High technology heat exchangers: Due to brand and heat exchanger, it
runs more efficiently.
Piscine Pompe À Chaleur Chauffe-Eau
Model No | RJ-48R/N2 | RJ-65R/N2 | RJ-85R/N2 | RJ-120R/N2 | RJ-180R/N2 |
Heating Capacity(W) | 4800 | 6500 | 8500 | 12000 | 18000 |
Cooling Capacity(W) | 3400 | 4500 | 6000 | 9000 | 13000 |
Input Power(W) | 970 | 1300 | 1700 | 2600 | 3830 |
Rating Current(A) | 4.44 | 5.95 | 7.78 | 11.90 | 17.53 |
Max Current(A) | 7.0 | 10.0 | 14.0 | 20.0 | 28.0 |
COP | 4.95 | 5.00 | 5.00 | 4.62 | 4.70 |
EER | 3.51 | 3.46 | 3.53 | 3.46 | 3.39 |
Alimentation | 230V~50Hz | ||||
La température de l'eau de la gamme | 15ºC~40ºC | ||||
Ambiante température de travail | -10ºC~43ºC | ||||
Dimension W?H?D | 800*493*300 | 986?550?360 | 986?550?360 | 1060?615?370 | 1195*685*470 |
Packing size WXHXD | 875*560*370 | 1057*663*380 | 1057*663*380 | 1135*723*390 | 1250*795*505 |
Net Weight/Gross Weight(KG) | 34/39 | 52/61 | 55/64 | 70/80 | 100/110 |
Noise dB(A) | =51 | =52 | =52 | =54 | =56 |
Water Pipe Connection | 2″ | 2″ | 2″ | 2″ | 2″ |
Air to Water Heat Exchanger | Titanium | ||||
Minimum Circulation Water Flow(L/MIN) | 40 | 40 | 60 | 80 | 100 |
Refrigerant | R410A | ||||
Contrôleur | LCD Wire controller | ||||
Working Mode | Heating/Cooling/Auto | ||||
Loading quantity(20′) | 156 | 96 | 96 | 90 | 38 |
