Piscine Pompe À Chaleur Chauffe-Eau

Terms of Payment: L/C,T/T
Supply Ability: 10000 Set/Sets per Year
Delivery Lead Time: 35days

Detailed Product Description
The product can be installed in many environments, including a constant
temperature swimming pool, sauna constant hot water system, or to supply
hot water at home.
Substitution de caractères distinguer des autres produits.

1.Automatic operation mode
2.Auto-restart, Auto defrost.
3.LCD Control panel with luxury outlook.
4.Cooling&heating.
5.Wide ambient range : -10 centigrade to 43centigrade
6.Japanese brand compressor
7.Green refrigerant R410

Les autres personnages principaux.

1) Long operating life: Using the advanced stainless steel/titanium
metal water heat exchanger, which resists the erosion from chlorine
in the water, creates a longer lifespan.
2) Economical and high-efficiency: Using heat pump technology, compared
with other ordinary hot water equipment (for example, combustion oil
boilers, combustion gas boilers, electronic boilers and so on), it
reduces operating costs by 65-80%, In addition it creates very little
pollution.
3) Bright design, easy installation and replacement: Unit design
separately for main model and water unit model, with water unit
inside, avoiding freezing in the winter. The unit is remarkably
compact, with pump and flow switch inside.
4) Advanced controlling: It is extremely easy to control. The swimming
pool heat pump unit is in the room, because of the mini-computer
intelligent controlling .
5) Safety: Water and electricity are insulated, no open fire, no creepage.
6) Quiet: Using the high-efficiency, low sound rotary or scroll compressor,
low noise fan, high quality pump, creates an extremely quiet machine.
7) High technology heat exchangers: Due to brand and heat exchanger, it
runs more efficiently.

Piscine Pompe À Chaleur Chauffe-Eau

Piscine Pompe À Chaleur Chauffe-Eau

Model No RJ-48R/N2 RJ-65R/N2 RJ-85R/N2 RJ-120R/N2 RJ-180R/N2
Heating Capacity(W) 4800 6500 8500 12000 18000
Cooling Capacity(W) 3400 4500 6000 9000 13000
Input Power(W) 970 1300 1700 2600 3830
Rating Current(A) 4.44 5.95 7.78 11.90 17.53
Max Current(A) 7.0 10.0 14.0 20.0 28.0
COP 4.95 5.00 5.00 4.62 4.70
EER 3.51 3.46 3.53 3.46 3.39
Alimentation 230V~50Hz
La température de l'eau de la gamme 15ºC~40ºC
Ambiante température de travail -10ºC~43ºC
Dimension W?H?D 800*493*300 986?550?360 986?550?360 1060?615?370 1195*685*470
Packing size WXHXD 875*560*370 1057*663*380 1057*663*380 1135*723*390 1250*795*505
Net Weight/Gross Weight(KG) 34/39 52/61 55/64 70/80 100/110
Noise dB(A) =51 =52 =52 =54 =56
Water Pipe Connection 2″ 2″ 2″ 2″ 2″
Air to Water Heat Exchanger   Titanium
Minimum Circulation Water Flow(L/MIN) 40 40 60 80 100
Refrigerant R410A
Contrôleur LCD Wire controller
Working Mode Heating/Cooling/Auto
Loading quantity(20′) 156 96 96 90 38
